| COOLING TOWER SPINNING NOZZLES |
|
|
|
The new SpinFree Nozzle produces a near perfect square
pattern, which provides balanced water loading. These two
features increase thermal performance in cooling towers
and other cooling equipment by 10 - 12% by simply changing out the
water nozzles.
The SpinFree nozzle has four major design features that each will
contribute significant value to the operations of cooling towers and
other heat transfer equipment.
- Square Spray Pattern
- The SpinFree nozzle produces a square water
distribution pattern, which will increase
thermal performance by 10%.
- Variable Flow Capabilities
- The SpinFree nozzle has variable flow capability
with a 2 to 1 turn down ratio, allowing pumps to be
> cycle off during cool climatic conditions or
when loads demands are down.
- Operates Just 3" off the Surface
- The SpinFree nozzle operates only 3” above the
fill media reducing structural height
requirements in new tower construction. Also this
feature reduces tower pump head by approximately 2
ft.
- Low Pressure Operation
- The SpinFree nozzle operates at a sweet spot of
only (1) lb of pressure as compared to 2lbs or
more for other nozzles.
-
- Download Catalogue :
Spin_Free.pdf
|
|
